HiVi RT2H-A Planar Isodynamic Tweeter Speaker Driver Replacement Part
The OEM HiVi RT2H-A is the perfect tweeter driver for your home audio speaker! It's a planar isodynamic tweeter rated at 30 watts with an impedance of 8 ohms.
Why Isodynamic? Contrary to a conventional dynamic driver, these transducers have a driving force distributed evenly over the whole area of their vibrating elements. The key feature of the RT2H-A is the membrane, which consists of Kapton film with a pattern of aluminum conductors. The membrane assembly is placed precisely between two rows of Neodymium and Barium Ferrite bar magnets. A larger membrane area provides higher power handling and substantially extended low-end cut-off frequency. These tweeters are magnetically shielded and are extremely flat with a depth of only 27mm, including the mounting flange.
OTHER PART NUMBERS ASSOCIATED WITH IT INCLUDE...
- RT2HA
- 844632021787
CONDITION
Like New. Never Used.
This is a never-before-used tweeter! It's in excellent shape and is ready to integrate into your speaker right out of the box.
📦 Professionally packed and shipped with care.
Cosmetic Condition: Very Good.
Functional Condition: Works Like New.
WHAT'S IN THE BOX?
- HiVi RT2H-A Planar Isodynamic Tweeter Speaker Driver Replacement Part
Other information about HiVi RT2HA
- Tweeter Type: Planar
- Power Handling (RMS): 30 Watts
- Impedance: 8Ω
- Frequency Response: 1,700 to 25,000Hz
- Sensitivity: 94dB 2.83V/1m
- Nearly weightless Kapton diaphragm for incredible transient response
- Semi-horn loaded faceplate for improved efficiency
- Large diaphragm can accommodate crossovers as low as 3,000 Hz
DIMENSIONS
- Overall Outside Diameter: 7.19" W x 6.63" H
- Cutout Diameter: 6.25" W x 6.13" H
- Depth: 1.75"
- No. of Mounting Holes: 4
