Swan HiVi TN25 2" Fabric Dome Tweeter Speaker Driver Part 5 Ohms
The Swan TN25 is the perfect replacement tweeter for your home audio speaker! It combines a hand-treated 1-inch fabric dome, a large non-resonant rear acoustic chamber, and a Ferrofluid cooled voice coil. The result is a high-performance tweeter with small faceplate for close driver placement. Plus, a self-shielded neodymium motor protects sensitive electronics while focusing the magnetic flux in the gap. It's the perfect driver for a DIY speaker or to replace a broken tweeter in your stereo speaker.
OTHER PART NUMBERS ASSOCIATED WITH IT INCLUDE...
- 844632021794
- 940824
- 940829
- 297-408
CONDITION
SPENCERTIFIED- Fully certified by Spencer
Refurbished and SPENCERTIFIED
Every function has been confirmed 100% working. All speaker parts have been cleaned. The speaker frame, dust cap, cone, and surround are in excellent condition.
Cosmetic Condition: Very Good.
Functional Condition: Works Like New.
WHAT'S IN THE BOX?
- Swan HiVi TN25 2" Fabric Dome Tweeter Speaker Driver Part 5 Ohms
Other information about Swan TN25
- Speaker Type: Tweeter
- Tweeter Type: Soft Dome
- Cone / Dome Diameter: 1"
- Cutout Diameter: 1.69
- Power Handling (Max): 30 Watts
- Impedance: 5Ω
- Frequency Response: 2,500 to 22,000Hz
- Sensitivity: 89dB 2.83V/1m
- Inherently shielded neo motor
- Fabric dome for a smooth, natural sound
- Large acoustic chamber reduces Fs for low crossover points
DIMENSIONS
- Overall Outside Diameter: 2.13"
- Overall Depth: 2.3"
- Hole to Hole: 2"
- No. of Mounting Holes: 4
MANUFACTURER
- Made in China
